Description
Rubber High Pressure Hose
The HYDROBLAST 4+ industrial high pressure hose has been specially developed for the high pressure cleaning industry. The hose has a working pressure of up to 1100 bar and is manufactured with only 4 spiral layers, so a 3/4″ hose can still be handled. The hose has a short bend radius, is lightweight and can be used in water temperatures up to +70°C
Hydroblast 4+ features
Suitable for high temperatures up to 70º C
Light and flexible
durable outer core
Certified to the latest NEN standards
Available with NPT or metric couplings
Available with 90º twist couplings M24 and M36
Available in 3/8” (DN10), 1/2” (DN12) and 3/4” (DN20)
Larger diameter couplings, less pressure loss
Available with safety marking rings or safety hose retaining rings
| HB4T.10.24.20 | HB4T12.24.20 | HB4T.20.36.20 | |
| Inside diameter | 3/8″ (9.5 mm) | 1/2″ (12.6 mm) | 3/4″ (19 mm) |
| Outside diameter | 20.4 mm | 24.6 mm | 32.0 mm |
| Bend radius | 210 mm | 230 mm | 250 mm |
| Length | 20 – 100 m | 20 – 100 m | 20 – 60 m |
| Max. working pressure | 1250 bar | 1100 bar | 1100 bar |
| Test pressure | 1875 bar | 1650 bar | 1650 bar |
| Burst pressure | 3125 bar | 2750 bar | 2750 bar |
| Weight | 0.88 kg/m | 1.22 kg/m | 1.87 kg/m |
