TECHNICAL CHARACTERISTICS
| Weight | Kg | 19,6 |
| Oil capacity | lt. | 1,2 |
| Inlet | G | 1/2” |
| Outlet | G | 3/8” |
| Part. No.
CODE |
Part. No.
CODE |
FLOW RATE | MAX PRESSURE | RPM | MAX POWER | TEMPERATURE | POWER TAKE-OFF | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L/MIN | US GPM | HP | KW | |||||||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | BAR | PSI | 50Hz | 60Hz | 50Hz | 60Hz | 50Hz | 60Hz | °C | °F | |||
| PX1150IL | 1.099-153.0 | 11 | 13 | 3 | 3.6 | 500 | 7250 | 1450 | 1740 | 14.3 | 17.2 | 10.5 | 12.6 | 65 | 150 |
 |
| PX1150IR | 1.099-154.0 | 11 | 13 | 3 | 3.6 | 500 | 7250 | 14.3 | 17.2 | 10.5 | 12.6 | 65 | 150 |
 |
||
| PX1550IL | 1.099-157.0 | 15 | 18 | 4 | 4.8 | 500 | 7250 | 19.4 | 23.3 | 14.3 | 17.2 | 65 | 150 |
|
||
| PX1550IR | 1.099-158.0 | 15 | 18 | 4 | 4.8 | 500 | 7250 | 19.4 | 23.3 | 14.3 | 17.2 | 65 | 150 |
|
||
| PX1750IL | 1.099-159.0 | 17 | 20 | 4.5 | 5.4 | 500 | 7250 | 21.4 | 25.7 | 15.8 | 19 | 65 | 150 |
|
||
| PX1750IR | 1.099-160.0 | 17 | 20 | 4.5 | 5.4 | 500 | 7250 | 21.4 | 25.7 | 15.8 | 19 | 65 | 150 |
|
||
| PX2150IL | 1.099-161.0 | 21.5 | 26 | 5.7 | 6.8 | 500 | 7250 | 27.6 | 33.1 | 20.3 | 24.4 | 65 | 150 |
|
||
| PX2150IR | 1.099-162.0 | 21.5 | 26 | 5.7 | 6.8 | 500 | 7250 | 27.6 | 33.1 | 20.3 | 24.4 | 65 | 150 |
|
||
